| Categories | AGV Automated Guided Vehicle |
|---|---|
| Brand Name: | TIANYUE |
| Model Number: | TY-FB-HZD-1 |
| Certification: | 3c.ce |
| Place of Origin: | GUANGZHOU |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 100 |
| Delivery Time: | 65 wrok days |
| Packaging Details: | wooden box |
| Motor Way: | Servo motor |
| Drive mode: | Dual steering wheel drive |
| Docking mod: | Back lift |
| Size: | Customization |
| Power supply: | Lithium iron phosphate |
| Load weight: | 1000KG |
| Project | Technical Parameters |
|---|---|
| Product Name | Single Lifting and Loading AGV |
| Product Dimensions | L x W x H mm (Customizable) |
| Loading Mode | Single Lifting Platform, X ±120mm, Y ±50mm, Rotation ±2° |
| Load Capacity | 1000 KG (Customizable) |
| Control Mode | PLC, Single Chip (Customizable) |
| Guidance Mode | Laser, QR Code, Magnetic Strip (Customizable) |
| Travel Directions | Forward, Reverse, Left Turn, Right Turn, Fork, 360° Rotation, Translation, Horizontal Movement, Omnidirectional |
| Drive Mode | Dual-Steering Wheel Drive |
| Drive Power Supply | DC 48V |
| Travel Speed | Linear: 0-40 m/min, Turning: 0-20 m/min |
| Repeat Positioning Accuracy | ±5mm |
| Allowable Road Surface Flatness | ≤5 mm |
| Operation Mode | Continuous 24-Hour Operation |
| Climbing Ability | ≤5% |
| Charging Mode | Online Charging (Side Charging) |
| Obstacle Sensor Safety Sensing Range | Detection Distance: ≤3 m (Adjustable), Sensor Detection Angle: ≤270° (Adjustable), Emergency Braking Distance: < 20 mm |
| Safety Protection | Front Obstacle Detection Sensor, Dual Protection Safety Bumper, Emergency Stop Switch |
| Alarm Form | Audible and Visual Alarm, Three-color Lamp, Music Horn |
| Working Noise | Below 70 dB (A) |
| Battery | Type: Lithium Iron Phosphate Battery, Voltage: 48V, Capacity: 210Ah |
| Design Life | >10 Years |
