R-R1000 Solid Wood Flooring Sanding Machine with 1000mm Maximum Processing Board Width

Categories	Woodworking Sanding Machine
Place of Origin:	Shandong, China
Brand Name:	PHOENIX EQUIPMENT
Condition:	New
Machine Type:	Vacuum adsorption sanding machine, Automatic Grinding Polishing
Video outgoing-inspection:	Provided
Machinery Test Report:	Provided
Marketing Type:	Ordinary Product
Warranty of core components:	1 Year
Core Components:	Motor
Warranty:	1 Year
Weight (KG):	1800 KG
Power (kW):	27.87kw
Key Selling Points:	Automatic
Showroom Location:	None
Applicable Industries:	Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Restaurant, Home Use, Construction works , Other, Advertising Company
Name:	Vacuum adsorption sanding machine
Product name:	wood thickness sand machine with vacuum
Voltage:	3-phase 380V 50HZ
Maximum processing board width:	1000mm
Maximum processed plate thickness:	1.5-110mm
Maximum length of processed sheet metal:	>25mm
belt speed:	20m/min
Conveying speed:	6-14m/min
Sandbag size:	1020*2000mm
Price:	$8,200.00/sets >=1 sets
MOQ:	1 set

Contact Now

Add to Cart

Products Description

Specification

Model	R-R1000
First sand motor	15kw
Second sand motor	11kw
Conveyor belt motor	1.5kw
Platform lifting motor	0.37kw
total power	27.87kw
Voltage	3-phase 380V 50HZ
Maximum processing board width	≦1000mm
Maximum processed plate thickness	1.5-110mm
Maximum length of processed sheet metal	＞25mm
Working air pressure	0.6-0.8mpa
belt speed	20m/min
Conveying speed	6-14m/min
Sandbag size	1020*2000mm
weight	1800kg
size	150018002100mm

Packing Delivery

1. Outside package: Standard marine export plywood cases.

2. Inner package: Stretch film and plastic film for humidity.

We can package according to your requests

Product Name	Vacuum adsorption sanding machine
Brand	PHOENIX EQUIPMENT
Customized	color, logo, voltage
MOQ	1 set
Package	plywood wooden box
Payment terms	Alibaba Trade Assurance, T/T, Alipay
Usage	Suitable for flat workpieces such as panel furniture, flat doors, solid wood composite flooring, cabinet side panels, handicrafts,bamboo and wood curtains, calcium silicate boards, glass magnesium boards, cement fiber boards, etc.
