Name: HSM645S Digital Stereoscopic Microscope with 3MP Camera
Brand: HUATEC
Price: 920 USD

HSM-645S Digital Stereoscopic Microscope with 3MP Camera

Categories	Non Destructive Testing Equipment
Brand Name:	HUATEC
Model Number:	HSM-645S
Certification:	CE
Place of Origin:	China
MOQ:	1 pc
Price:	USD920/set - USD1030/set
Payment Terms:	T/T,Paypal
Supply Ability:	10sets/Month
Delivery Time:	7-10 working days after receipt of your payment
Packaging Details:	Carton packing box
Working distance:	115mm
Changing times than:	6.3:1.
Changing times objective:	0.8~5X(total amplification 8~50X) (optional up to 4 ~ 100X)
Sight glass tube:	Tritocular lens with an inclination of 45°
Visibility adjustable eyepiece:	Wide field flat field eyepiece EW10X / / Φ 22

Contact Now

Add to Cart

Product Details
Company Profile

HSM-645S Digital Stereoscopic Microscope with 3MP Camera

HSM-645S High Resolution Numerical Digital Camera Stereoscopic Microscope

System description

HSM-645S stereoscopic microscope is the best microscope in the domestic microscope, for Japan NIKON OEM production;
The stereoscopic microscope is connected with the digital camera, the microscopic image can realize the high resolution numerical, the total pixel is more than three million pixels of high resolution, the photos into the computer system to save and print, can be realized as required to print;
The use of the computer can be used laptop computer, simple operation, easy to carry;
The measurement of various parameters of image is comprehensive and accurate.
The image scale can be superimposed on the photograph to always determine the magnification and always meet the requirements of the laboratory report.

Specifications and parameters

project	parameter	HSM-645S
Sight glass tube	Binocular lens with an inclination of 45°
	Tritocular lens with an inclination of 45°	●
	Digital volumetric lens body, Angle of 45°
Visibility adjustable eyepiece	Wide field flat field eyepiece EW10X / / Φ 22	●
	WF15X / Φ 16	○
	WF20X / Φ 12	○
	WF30X	○
Changing times objective	0.8~5X(total amplification 8~50X) (optional up to 4 ~ 100X)	●
Changing times than	6.3:1.	●
Working distance	115mm	●
pd	52-75mm	●
The auxiliary lens	0.5 x	○
	0.7 x	○
	2 x	○
The loading platform is inserted into the circular plate	Transparent glass plate 140mm in diameter	●
The loading platform is inserted into the circular plate	Black and white board	○
Lighting system	No light	○
	Reflected light 100V-240V/LED	●
	Transmitted light lighting 100V-240V/LED	●

● standard configuration, ○ optional configuration

options

A. Computers and printers

B. Metallographic Image analysis and measurement software (Image-3000)

Product features:

1. Anti - static function: stand, zoom lens barrel, 10X eyepiece, auxiliary objective lens, etc.

2. Sealing function: magnification cylinder, 10X eyepiece have sealing function, when the microscope in oil, steam, water vapor and other high humidity environment is still convenient to use.

3. Mildew resistance: safe in high temperature or humid environment.

4. It has the characteristics of high definition, large field of view, long working distance and so on, and reproduces the three-dimensional image of the object realistically.

5. Creative ergonomics design, more guarantee the operator a long time comfortable operation.
