Zonewu LoRaWAN Optical Dissolved Oxygen Sensor

Product Features:

LoRaWAN dissolved oxygen sensor is a wireless dissolved oxygen sensor that uses fluorescence measurement principle. It is designed for scenarios such as outdoor, factory, aquaculture, etc. where power supply is inconvenient or scattered at multiple locations. Built in ER26500 lithium-ion battery (8500 mAh, 3.6V), combined with LoRa low-power communication technology, can achieve maintenance free operation for more than a year, truly solving the problems of difficult wiring and power supply in traditional wired monitoring.

1, Fluorescence method measurement, no oxygen consumption or calibration required
Using advanced optical fluorescence technology, the sensor measures the fluorescence quenching effect to invert the dissolved oxygen concentration, without consuming oxygen, and is not affected by flow rate and electromagnetic interference, making the measurement more stable. Supports a wide range of 0-20mg/L (0-200% saturation), with a resolution of up to 0.01mg/L and an accuracy of ± 3% FS. Coupled with high-precision temperature compensation of ± 0.5 ℃, it ensures the authenticity and reliability of the data.
2, Available in both freshwater and seawater versions, suitable for different water bodies
Provide two models, LDO (freshwater version) and LDOS (seawater version), optimized for freshwater environments (such as rivers, lakes, and tap water) and high salinity seawater environments (such as marine aquaculture and nearshore monitoring), respectively, to meet the precise monitoring needs of multiple scenarios.
3, Long life fluorescent film, easier to maintain
The lifespan of fluorescent film can reach one year under normal usage conditions, significantly reducing replacement frequency and backend maintenance costs. The sensor comes standard with a 5-meter cable by default (length can be customized), supporting a pressure resistance of 0.6Mpa, suitable for deep water or pipeline installation environments.
4, LoRaWAN wireless transmission, compatible with global frequency bands
Supports global mainstream LoRaWAN frequency bands such as CN470/IN865/EU868/US915/AU915/KR920/AS923, out of the box, can quickly connect to standard LoRa gateways and cloud platforms, and achieve remote real-time viewing of dissolved oxygen change trends, historical data playback, and threshold alarms.
5, Extremely low power consumption design, battery powered long-lasting durability
Excellent overall power consumption control, relying on LoRaWAN Class C mode and configurable reporting cycle (default 10 minutes), a single battery can support long-term field deployment without the need for external solar or mains power, making it particularly suitable for the construction of distributed water quality monitoring networks.

Packaging:

Single gross weight: 1.200 KG

Single package size: 37X26X5 cm

Product Display:

Quality assurance:

• Each production process is inspected by dedicated personnel to strictly ensure product quality.
• Professional engineers are responsible for quality inspection and control throughout the entire process.
• All products have passed authoritative certifications such as CE, ROHS, and metrology.

Application:

• Aquaculture: Real time monitoring of dissolved oxygen in fish ponds, shrimp and crab breeding ponds, etc. to prevent oxygen deficiency from flooding the pond.
• Surface water monitoring: Long term unmanned monitoring of outdoor water bodies such as rivers, lakes, and reservoirs.
• Wastewater treatment: Biochemical tank, aeration tank, precise control of dissolved oxygen, optimized aeration energy consumption.
• Emergency and remote monitoring: Water pollution emergency deployment points, remote water areas without power supply, rapid deployment.

FAQ:

1.Are you manufacture?

A:Yes,we are Tranmitter manufacturer and exporter in China with more than 10 years of CE,ROHS,FCC,ISO and 11 patents experience.

2.Do you offer OEM services?

A:Yes,we can provide you with OEM services and design housings and logos.

3.DO you offer free samples?

A:Sorry,we don't offer free samples.After ordering in bulk,we will deduct the sample fee from the second order.

Why choose us:

• Strong R & D: 30+ Senior experts and highly educated personnel formed a R & D team, heavy investment, master a number of core technologies and patents.
• Professional and effective solutions: for smart environmental protection, agriculture and other fields, to provide customized compound networking solutions.
• Full range of products: covering the whole industry chain products from data collection to platform services to meet diverse needs.
• Excellent quality: we have perfect quality control system, strictly quality control each production link, low defective rate.
• Good service: 7×24 hours fast response, Professional pre-sale, sale, after-sales team support.

ZONEWU is a professional provider of LoRaWAN IoT sensors and wireless sensing solutions. We focus on industrial-grade, low-power, long-range sensors for smart industry, agriculture, environment and smart city. We deliver reliable products and customized services to global system integrators and clients.
