2.2 Inch STN Display Dot Matrix LCD Module with UC1604c Drive IC for Industrial and Consumer Electronics

Specifications:

1.Display Mode: STN(BLUE)/Transflective/Negative
2.Viewing Angle: 6 0'clock.

3.Drive Method:1/64 Duty,1/9 Bias,Vop=10.0V,Vdd=3.3V.
4.Top: -20°C~+70°C

Tst: -30°C~+80°C.
5. Connector: COG+FPC.
6. Drive IC: UC1604c

Primary Application Areas

1.Industrial Control

Equipment status display

Instrumentation panels

2.Consumer Electronics

Portable device displays

Home appliance interfaces

3.Medical Devices

Portable medical instruments

Basic diagnostic devices

4.Transportation Systems

Shared device lock screens

In-vehicle information terminals

5.Retail & Payment

POS systems

Electronic shelf labels

6.Communication Devices

Walkie-talkie status screens

Network equipment indicators

Shenzhen Enrich Electronics Co ., Ltd .is a manufacturer and solution provider of intelligent terminal displays integrating R&D, design, production, sales and service .,The company 's main products include LCD liquid crystal display, LCM monochrome display module, TFT color display module and OLED display , including segment type ,dot matrix type and other types and COG, COB and other different process structures, covering TN, HTN, STN, FSTN, VA(BTN) and other different display modes , according to Different application requirements of customer products , flexible and professional design of corresponding display solutions; Products have been widely used in power meters , industrial equipment control, home appliance control, sports equipment, automotive instruments, smart wear, communication equipment , medical equipment , financial payment terminals,ETC electronic label and other fields.

Core Products & Technologies

Full-range Micro Displays:

TFT LCD Module (0.42~10.1”): IPS/FFS wide-view

Segment Displays: Custom segment design, ultra-low power (μA level)

Dot Matrix LCDs: Mono/tri-color, industrial temp range (-30℃~85℃)
