| Categories | Tungsten Carbide Burrs |
|---|---|
| Brand Name: | CBT |
| Model Number: | SN-4M DC |
| Certification: | ISO9001：2008 |
| Place of Origin: | CHINA |
| MOQ: | 50 PCS |
| Price: | 1-5usd/pc |
| Payment Terms: | T/T,L/C,Western Union |
| Supply Ability: | 70000pcs/month |
| Delivery Time: | 15-30 days |
| Packaging Details: | carton43*25*22.5cm |
| model: | SN-4M DC |
| cut dia: | 12.7mm |
| cut length: | 12.7mm |
| shank dia: | 6mm |
| overall: | 58mm |
| cut: | DC |
| type: | silver braze |
| coating: | no |
| material: | Tungsten Carbide |
| grade: | YG7 |
| workpiece: | Steel, Cast Iron |
The eco-friendly fast removal carbide rotary burr is designed for rapid material removal, utilizing low-dust cutting technology to reduce environmental pollution during processing. Its optimized chip evacuation structure ensures a clean work area even during high-efficiency operations, making it suitable for manufacturing scenarios with strict environmental requirements.
| Technical Parameters | ||||||
| Model | Cut dia (D1) | Cut length (D2) | Shank (L1) | Overall (L2) | Type | Cut |
| SN-4M DC | 12.7 | 12.7 | 6 | 58 | Silver braze | Double |
| Care Selections-carbide grades | Cobalt(%) | Hardness(HRA) | T.R.S(N/mm2) | |
| Carbide Grades | YG7 | 7 | 90.5 | 3000 |
| YG8 | 8 | 89.5 | 3400 | |
| YG6X | 6 | 91.7 | 3400 | |
| YG10X | 10 | 90-91 | 3000 | |
This tool prioritizes operational safety, featuring low-vibration design and chip-containment structures to reduce work risks. The ergonomic shank design reduces operator fatigue and provides a stable grip, ensuring safety and efficiency during prolonged continuous use.
Caburtech offers a wide selection of carbide burr shapes in Single and Double Cut styles, including Cylinder, Round nose cylinder, Ball, Oval, Tree, Flame, Cone, Countersink and Inverted Cone. Each shape is designed for grinding, deburring, chamfering, and finishing on steels under 60 HRC, stainless steels, cast iron and etc.
|
