HASL Prototype Electronics PCB Assembly Multipurpose Practical

Categories	Electronics PCB Assembly
Brand Name:	OEM Customized
Model Number:	HKCC2211YH87
Certification:	UL, SGS, RoHS, ISO14001
Place of Origin:	China
MOQ:	2pcs
Price:	USD10-USD100
Payment Terms:	L/C, T/T
Supply Ability:	20000 Square Meters per Month
Delivery Time:	20 workdays
Packaging Details:	Inner packing :bubble bag Outer packing :Standard carton box
Warp and twist:	0.7%(semiconductor test board ≤.3%)
Finished surface:	Conventional HASL, Lead-free HASL, Falsh Gold
Base Material:	High TG FR-4 / Rgon/sola//Rogers
Profiling puching:	V-cut, rounting
PCBA test:	X-ray, AOI Test
Solder Type:	Lead-free – RoHS
Twisting and Bending:	≤ 0.75%, Min: 0.5%

Contact Now

Add to Cart

Product Details
Company Profile

HASL Prototype Electronics PCB Assembly Multipurpose Practical

Product Description

Support Small Batch Fast Prototype Sample Fabrication 4G WIFI Electronic Components PCBA

Files and Requirment for PCB,PCBA quotation:

A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements

PCB board manufacture and PCBA service:
- o PCB board made, circuit board parts purchased by us
- o Electronic testing circuit board or PCBA
- o Fast delivery, anti-static package
- o RoHS Directive-compliant, lead-free
- o One stop service from PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery
- o Eleectronic manufacturing service
Detailed terms for PCB assembly:
- o Technical requirement:
  - § Professional surface-mounting and through-hole soldering technology
  - § Various sizes like 1206, 0805, 0603 components SMT technology
  - § ICT (In Circuit Test), FCT (Functional Circuit Test) technology
  - § PCB assembly with UL, CE, FCC, RoHS approval
  - § Nitrogen gas reflow soldering technology for SMT
  - § High standard SMT and solder assembly line
  - § High density interconnected board placement technology capacity
- o Quote requirement:
  - § Gerber file and Bom list
  - § Clear pics of pcba or pcba sample for us
  - § Test method for PCBA
- o PCB specification:
  - § Layer: 1 to 12 layers
  - § Material: FR-4, CEM-1, CEM-3, Hight TG, FR4 halogen free, FR-1, FR-2,Aluminum etc.
  - § Max. finished thickness: 0.2 to 4.0mm (0.02 ~ 0.25″)
  - § Max. finished board side: 500 x 500mm (20 x 20”)
  - § Min. drilled hole size: 0.25mm (10mil)
  - § Min. line width: 0.10mm (4mil)
  - § Min. line spacing: 0.10mm (4mil)
  - § Surface finish/treatment: HALS/HALS lead free, chemical tin, chemical gold, immersion gold, plating gold
  - § Copper thickness: 0.5 to 3.0 oz
  - § Solder mask color: green/black/white/red/blue
  - § Inner packing: plastic bag
  - § Outer packing: standard carton packing
  - § Hole tolerance: PTH: ±0.076, NTPH: ±0.05
  - § Certificate: UL, ISO 9001, ISO 14001, RoHS,UL
  - § Profiling punching: routing, V-cut, beveling
  - § Providing OEM service to all sorts of printed circuit board assembly

Warp and twist	0.7%(semiconductor test board ≤.3%)
Finished surface	Conventional HASL, Lead-free HASL, Falsh Gold
Base Material	High TG FR-4 / Rgon/sola//Rogers
Supply Ability	20000 Square Meters per Month
Profiling puching	V-cut, rounting
PCBA test	X-ray, AOI Test
Solder Type	Lead-free – RoHS
Twisting and Bending	≤ 0.75%, Min: 0.5%
Range of TG	130 - 215 ℃
Impedance Tolerance	±10%, Min: ± 5%

HASL Electronics PCB Assembly

Multipurpose Electronics PCB Assembly

Practical Prototype Electronics Assembly

HASL Prototype Electronics PCB Assembly Multipurpose Practical
